Serial Port AIS Receiver AIS-RUS01

The AIS-RUS01 is a portable and professional small-scale AIS receiver. It is a dual-channel AIS receiver integrated with a low noise amplifier (LNA), featuring compact size, lightweight, and low power consumption. The device can output data simultaneously via USB and serial port. The serial interface supports the RS232 protocol by default, with optional RS485 support available (please inform us of the selected option before shipment). RS422 or TTL customization is also available.

· Compact size, light weight, low power consumption

· Outputs standard AIVDM message format

· Supports AIS message types 1-27

· Supports dual AIS channels

· Highly configurable for various application scenarios

· Optional output of AIS signal strength

· Optional reception of “Long-Range AIS” signals

· Supports USB/serial port output

Interface：

What makes AIS-RUS01 different from ordinary USB AIS receivers?
AIS-RUS01 is designed as a professional and flexible AIS receiving device, rather than simply a USB AIS receiver for connecting to a computer.
Unlike many ordinary AIS USB receivers, AIS-RUS01 supports both USB and serial data output, making it suitable not only for PC-based AIS monitoring but also for integration into professional systems and equipment.
This makes AIS-RUS01 suitable for applications such as AIS monitoring systems, vessel tracking systems, coastal surveillance, research projects and OEM system integration.

Can AIS-RUS01 be integrated into other systems?
Yes.
AIS-RUS01 is suitable for OEM integration and customized system applications.
Because it provides standard AIS data output and flexible interface options, it can be integrated into systems such as:
· Vessel tracking systems
· Maritime surveillance systems
· Coastal monitoring systems
· Port monitoring systems
· Research and laboratory systems
· Maritime information platforms
· Customized monitoring equipment
For OEM projects, the device can also be customized according to specific requirements, including interfaces, enclosure, branding and other features.

Is AIS-RUS01 suitable for portable applications?
Yes.
AIS-RUS01 features a compact and lightweight design, making it convenient for portable and temporary deployment.
Its low power consumption and USB power supply make it convenient for applications where portability and simple deployment are important.

Can AIS-RUS01 be used with AIS display software?
Yes.
AIS-RUS01 can be connected to compatible AIS display and navigation software.
For example, the product manual describes using the receiver with OpenCPN through a serial connection.
After selecting the correct COM port and communication settings, received AIS data can be displayed on the software interface.
This allows AIS-RUS01 to be used for applications such as vessel monitoring, AIS demonstrations and maritime research.

What antenna options are available for AIS-RUS01?
AIS-RUS01 can be supplied with different antenna options depending on the application.
A compact AIS antenna is available for portable and general-purpose applications.
For professional outdoor installations, a professional AIS antenna is also available as an option.
